尺寸Nominal Bearing Bore

Recommended

内径Instrlled Bearing I.D.

轴承长度及轴承规格Bearing Length and Part Number

轴径Shaft Dia.

座孔Housing Bore

1/3

5/32

3/16

1/4

3/8

1/2

5/8

3/4

7/8

1

11/8

11/4

11/2

1/8

0.1243 0.1236

0.1873 0.1878

0.1243 0.1268

02/02

02/03

5/32

0.1554 0.1547

0.2186 0.2191

0.1556 0.1581

025/025

025/04

3/16

0.1865 0.1858

0.2497 0.2503

0.1867 0.1893

03/03

03/04

03/06

1/4

0.2490 0.2481

0.3122 0.3128

0.2492 0.2518

04/04

04/06

5/16

0.3115 0.3106

0.3747 0.3753

0.3117 0.3143

05/06

05/08

3/8

0.3740 0.3731

0.4684 0.4691

0.3742 0.3769

06/03

06/04

06/06

06/08

06/10

06/12

7/16

0.4365 0.4355

0.5309 0.5316

0.4367 0.4394

07/08

07/12

1/2

0.4990 0.4980

0.5934 0.5941

0.4992 0.5019

08/04

08/06

08/08

08/10

0812

0814

9/16

0.5615 0.5605

0.6559 0.6566

0.5617 0.5644

09/06

09/08

09/10

09/12

5/8

0.6240 0.6230

0.7184 0.7192

0.6242 0.6270

10/04

10/08

10/10

10/12

10/14

10/16

11/16

0.6865 0.6855

0.7809 0.7817

0.6867 0.6895

11/14

3/4

0.7491 0.7479

0.8747 0.8755

0.7493 0.7525

12/04

14/06

12/08

12/10

12/12

12/16

13/16

0.8116 0.8106

0.9372 0.9380

0.8118 0.8150

13/12

13/18

7/8

0.8741 0.8729

0.9997 1.0005

0.8743 0.8775

14/04

14/06

14/12

14/16

14/20

1

0.9991 0.9979

1.1247 1.1255

0.9993 1.0025

16/06

06/08

16/12

16/16

16/20

16/24

11/8

1.1238 1.1226

1.2808 1.2818

1.1240 1.1278

18/06

18/10

18/12

18/16

11/4

1.2488 1.2472

1.4058 1.4068

1.2490 1.2528

20/06

20/12

20/14

20/16

20/20

13/8

1.3738 1.3722

1.5308 1.5318

1.3740 1.3778

22/12

22/16

22/24

11/2

1.4988 1.4972

1.6558 1.6568

1.4990 1.5028

24/08

24/16

24/18

24/20

24/24

15/8

1.6238 1.6222

1.7808 1.7818

1.6240 1.6278

26/16

26/24
