Bearing Unit NO. |
Shaft Dia
d |
Dimensions(mm) |
Bolt Used |
Bearing
No. |
Housing
No. |
Weight
(kg) |
|
(in) |
(mm) |
a |
p |
e |
i |
s |
j |
k |
g |
f |
z |
Bi |
n |
mm |
in |
|
UCFCF205-13
UCFCF205-14
UCFCF205-15
UCFCF205-16
UCFCF205 |
13/16
7/8
15/16
1 |
25 |
111 |
92 |
65.1 |
11 |
10.3 |
6.4 |
9.5 |
22 |
76.2 |
30.8 |
34.1 |
14.3 |
M8 |
5/16 |
UC205-13
UC205-14
UC205-15
UC205-16
UC205 |
FCF205 |
0.99 |
|
UCFCF206-17
UCFCF206-18
UCFCF206-19
UCFCF206-20
UCFCF206 |
1-1/16
1-1/8
1-3/16
1-1/4 |
30 |
127 |
105 |
74.2 |
7.5 |
12 |
11 |
9.5 |
20 |
85.7 |
29.7 |
38.1 |
15.9 |
M10 |
3/8 |
UC206-17
UC206-18
UC206-19
UC206-20
UC206 |
FCF206 |
1.36 |
|
UCFCF207-20
UCFCF207-21
UCFCF207-22
UCFCF207-23
UCFCF207 |
1-1/4
1-5/16
1-3/8
1-7/16 |
35 |
133 |
111 |
78.5 |
7.1 |
12 |
12 |
13 |
22 |
92 |
32.5 |
42.9 |
17.5 |
M10 |
3/8 |
UC207-20
UC207-21
UC207-22
UC207-23
UC207 |
FCF207 |
1.76 |
|
UCFCF208-24
UCFCF208-25
UCFCF208 |
1-1/2
1-9/16 |
40 |
133 |
111 |
78.5 |
9.5 |
12 |
12 |
13 |
26 |
92 |
39.7 |
49.2 |
19 |
M10 |
3/8 |
UC208-24
UC208-25
UC208 |
FCF208 |
1.93 |
|
UCFCF209-26
UCFCF209-27
UCFCF209-28
UCFCF209 |
1-5/8
1-11/16
1-3/4 |
45 |
156 |
130 |
92 |
5.6 |
13.5 |
12 |
11.5 |
22 |
108 |
37.6 |
49.2 |
19 |
M12 |
7/16 |
UC209-26
UC209-27
UC209-28
UC209 |
FCF209 |
2.38 |
|
UCFCF210-29
UCFCF210-30
UCFCF210-31
UCFCF210-32
UCFCF210 |
1-13/16
1-7/8
1-15/16
2 |
50 |
162 |
137 |
96.5 |
8.7 |
13.5 |
16 |
13 |
27 |
114 |
41.3 |
51.6 |
19 |
M12 |
7/16 |
UC210-29
UC210-30
UC210-31
UC210-32
UC210 |
FCF210 |
2.93 |
|
UCFCF211-32
UCFCF211-33
UCFCF211-34
UCFCF211-35
UCFCF211 |
2
2-1/16
2-1/8
2-3/16 |
55 |
181 |
152 |
108 |
5.6 |
15 |
22.2 |
13 |
22.2 |
127 |
39 |
55.6 |
22.2 |
M12 |
7/16 |
UC211-32
UC211-33
UC211-34
UC211-35
UC211 |
FCF211 |
3.67 |
