Bearing Unit NO. |
Shaft Dia d |
Dimensions(mm) |
Bolt Used |
Bearing No. |
Housing No. |
Housing
Wt (kg) |
|
|
(in) |
(mm) |
a |
e |
i |
g |
l |
S |
S1 |
S2 |
b |
f |
z |
Bi |
n |
mm |
in |
|
|
UCFA201-8
UCFA202-9
UCFA202-10
UCFA203-11
UCFA204-12
UCFA201
UCFA202
UCFA203
UCFA204 |
1/2
9/16
5/8
11/16
3/4
|
12
15
17
20 |
98 |
78 |
15 |
12 |
25.5 |
10 |
10 |
40 |
60 |
50 |
33.3 |
31 |
12.7 |
M8 |
5/16 |
UC201-8
UC202-9
UC202-10
UC203-11
UC204-12
UC201
UC202
UC203
UC204 |
FA204 |
0.3 |
|
|
|
|
UCFA205-13
UCFA205-14
UCFA205-15
UCFA205-16
UCFA205 |
13/16
7/8
15/16
1 |
25 |
125 |
98 |
16 |
14 |
27 |
12 |
13 |
51 |
68 |
65 |
35.7 |
34 |
14.3 |
M10 |
3/8 |
UC205-13
UC205-14
UC205-15
UC205-16
UC205 |
FA205 |
0.5 |
|
|
UCFA206-17
UCFA206-18
UCFA206-19
UCFA206-20
UCFA206 |
1-1/16
1-1/8
1-3/16
1-1/4 |
30 |
144 |
117 |
18 |
14 |
31 |
12 |
13 |
58 |
80 |
72 |
40.2 |
38.1 |
15.9 |
M10 |
3/8 |
UC206-17
UC206-18
UC206-19
UC206-20
UC206 |
FA206 |
0.65 |
|
|
UCFA207-20
UCFA207-21
UCFA207-22
UCFA207-23
UCFA207 |
1-1/4
1-5/16
1-3/8
1-7/16 |
35 |
161 |
130 |
19 |
16 |
34 |
14 |
15 |
66 |
90 |
82 |
44.4 |
42.9 |
17.5 |
M12 |
7/16 |
UC207-20
UC207-21
UC207-22
UC207-23
UC207 |
FA207 |
0.9 |
|
|
UCFA208-24
UCFA208-25
UCFA208 |
1-1/2
1-9/16 |
40 |
175 |
144 |
21 |
16 |
36 |
14 |
15 |
71 |
100 |
87 |
51.2 |
49.2 |
19 |
M12 |
7/16 |
UC208-24
UC208-25
UC208 |
FA208 |
1 |
|
|
UCFA209-26
UCFA209-27
UCFA209-28
UCFA209 |
1-5/8
1-11/16
1-3/4 |
45 |
181 |
148 |
22 |
18 |
38 |
16 |
17 |
72 |
108 |
90 |
52.2 |
49.2 |
19 |
M14 |
1/2 |
UC209-26
UC209-27
UC209-28
UC209 |
FA209 |
1.2 |
|
|
UCFA210-29
UCFA210-30
UCFA210-31
UCFA210-32
UCFA210 |
1-13/16
1-7/8
1-15/16
2 |
50 |
190 |
157 |
22 |
18 |
40 |
16 |
17 |
76 |
115 |
94 |
54.6 |
51.6 |
19 |
M14 |
1/2 |
UC210-29
UC210-30
UC210-31
UC210-32
UC210 |
FA210 |
1.4 |
|
|
UCFA211-32
UCFA211-33
UCFA211-34
UCFA211-35
UCFA211 |
2
2-1/16
2-1/8
2-3/16 |
55 |
219 |
184 |
25 |
20 |
43 |
16 |
17 |
86 |
130 |
104 |
58.4 |
55.6 |
22.2 |
M14 |
1/2 |
UC211-32
UC211-33
UC211-34
UC211-35
UC211 |
FA211 |
2.3 |
|
|
UCFA212-36
UCFA212-37
UCFA212-38
UCFA212-39
UCFA212 |
2-1/4
2-5/16
2-3/8
2-7/16 |
60 |
240 |
202 |
29 |
18 |
48 |
18 |
19 |
100 |
140 |
120 |
68.7 |
65.1 |
25.4 |
M16 |
5/8 |
UC212-36
UC212-37
UC212-38
UC212-39
UC212 |
FA212 |
2.75 |
|
|
UCFA213-40
UCFA213-41
UCFA213 |
2-1/2
2-9/16 |
65 |
248 |
210 |
30 |
20 |
49 |
18 |
19 |
106 |
152 |
126 |
69.7 |
65.1 |
25.4 |
M16 |
5/8 |
UC213-40
UC213-41
UC213 |
FA213 |
3.35 |
|
