MINEBEA	B	D	W	H	F	TH	L	N	P	C	S	α	O	S	Static Limit Load		Radial Static Ultimate Load	Fatigue Load	Approx. Weight
Part	H7	±0.5	0	±0.13	±0.5	JIS Class 2	±0.7	±0.5	±0.5	0.2	±0.25	(deg.)	Ref.	DB	kN(3)		-3	-3	g
No.			-0.1							-0.7				Ref.	Radial	Axial	kN	kN
HRT3	3	16	7	5.3	30	M3×0.5	16	7	9	3.5	8	18	5.2	8.7	15	2	31	5.1	29
HRT4	4	18	9.5	7.8	32	M4×0.7		8.5	11		10	16	5.8	11	31	3.5	43	7.2	35
HRT5	5	21	11	8.8	35	M5×0.8	19	11	15	4.5	12	15	7.8	13	28	5.1	35	5.8	40
HRT6	6	21			37	M6×1.0
HRT8	8	23		8.3	41	M8×1.25	22	13	17	6.5	14	14	11	15	34	5.3	42	7.1	51
HRT10	10	26	13	11	46	M10×1.5	24	14	19		15	8	12	17	38	6.8	47	7.8	73
HRT12	12	34	16	13	57	M12×1.75	32	19	24		20	10	15	22	78	8.3	98	16	150
HRT14	14	36	17	14	60	M14×2.0	33	19		7.5		8	19	25	83	9	104	17	165
HRT15	15	38	18		62		34	20	25	8.5	21	11	19	26	95	9.3	119	20	189
HRT16	16	39	19	15	64	M16×2.0	35	22	27	9.5	23	10	19	27	101	9.7	126	21	218
HRT17	17	41	20		68	M16×1.5	37	23	28		24	12	20	29	101	10	127	21	241
HRT18	18	43		16	74	M18×1.5	40	24	30	10	26	10			121	12	151	25	283
HRT20	20	45	22		76	M20×1.5	41	25			26	13	23	32	121	13	152	25	330
HRT22	22	52		19	85	M22×1.5	47	28	36	12	30	6	27	35	156	15	195	33	580
HRT25	25	70	35	25	105	M24×2.0	54	42	50	14	43	15	32	48	302	21	378	63	1230
HRT28	28	75			110	M27×2.0	58	44	56	15	47	14	37	51	284	23	355	59	1620
HRT30	30	78	37	26	120	M30×2.0	62	48	60	16	51		40	55	272	25	340	57	1930
