MINEBEA	B	D	W	H	F	TH	L	α	O	S	N·m	Static Limit Load		Radial Static Ultimate Load	Fatigue Load (3)	Approx. Weight
Part	H7	±0.50	0	±0.13	±0.5	JIS Class 2	±0.7	(deg.)	Ref.	DB		kN(3)		(3) kN	kN	g
No.			-0.1							Ref.		Radial	Axial (2)
HRT3E	3	16	7	5.25	30	M3×0.5	10	18	5.2	8.73	0.06	3.62	1.96	4.51	0.73	25
HRT4E	4	18	9.5	7.75	35	M4×0.7	16	16	5.8	11.11		6.27	3.53	7.84	1.27	30
HRT5E	5	20.5	11	8.75	39.5	M5×0.8	22	15	7.8	13.49	0.68	10.29	5.09	12.84	2.1	35
HRT6E	6					M6×1.0						14.51		18.14	2.99
HRT8E	8	23		8.25	46	M8×1.25	29	14	10.9	15.48	0.12	26.77	5.29	33.44	5.54	40
HRT10E	10	26	12.5	10.75	47	M10×1.5		8	12.2	17.46		37.65	6.76	47.07	7.84	65
HRT12E	12	34	16	13.25	62	M12×1.75	37	10	15.4	22.22		62.46	8.33	78.06	12.94	126
HRT14E	14	36	17	14.25	64	M14×2.0	38	8	18.9	25.4	1.13	82.96	9.02	103.65	17.25	140
HRT15E	15	38	18		65			11	19	26.19		100.71	9.7	125.81	20.98	165
HRT16E	16	39	19	15.25	66.5	M16×2.0	39.5	10	19.2	26.99						195
HRT17E	17	41	20		72.5	M16×1.5	42	12	20.4	28.58		101.4	10.29	126.7	21.08	220
HRT18E	18	43		16.3	79.5	M18×1.5	46	10				120.62	12.16	150.72	25.1	250
HRT20E	20	45	22		83	M20×1.5	50	13	22.9	31.75		121.3	12.84	151.61	25.2	290
HRT22E	22	52		19.3	86	M22×1.5	51	6	27.1	34.92	0.23	156.21	15.1	195.25	32.55	450
HRT25E	25	70	35	25.3	105	M24×2.0	59	15	32.3	47.62		300.08	20.88	375.1	62.56	1150
HRT28E	28	75			110	M27×2.0	62	14	36.8	50.8	1.8	283.7	23.24	354.6	59.13	1500
HRT30E	30	78	37	26.3	120	M30×2.0	65		40.4	54.77		271.93	24.81	339.89	56.68	1800
