Bearing No.		Boundary dimensions mm			Basic Load Rating KN		Speed Rating r/min		Weight kg
10000 (TN1,M) Cylindrical	10000K (TN1,M) Tapered Bore	d	D	B	Cr	Cor	Grease Lubrication	Oil Lubrication
1203	1203K	17	40	12	7.90	2.02	16000	20000	0.076
2203	2203K		40	16	9.00	2.45	16000	20000	0.09
1303	1303K		47	14	12.5	3.18	14000	17000	0.14
2303	2303K		47	19	14.5	3.58	13000	16000	0.17
1204	1204K	20	47	14	9.95	2.65	14000	17000	0.12
2204	2204K		47	18	12.5	3.28	14000	17000	0.15
1304	1304K		52	15	12.5	3.38	12000	15000	0.17
2304	2304K		52	21	17.8	4.75	11000	14000	0.22
1205	1205K	25	52	15	12.0	3.30	12000	14000	0.14
2205	2205K		52	18	12.5	3.40	12000	14000	0.19
1305	1305K		62	17	17.8	5.05	10000	13000	0.26
2305	2305K		62	24	24.5	6.48	9500	12000	0.35
1206	1206K	30	62	16	15.8	4.70	10000	12000	0.23
2206	2206K		62	20	15.2	4.60	10000	12000	0.26
1306	1306K		72	19	21.5	6.28	8500	11000	0.398
2306	2306K		72	27	31.5	8.68	8000	10000	0.50
1207	1207K	35	72	17	15.8	5.08	8500	10000	0.32
2207	2207K		72	23	21.8	6.65	8500	10000	0.44
1307	1307K		80	21	25.0	7.95	7500	9500	0.54
2307	2307K		80	31	39.2	11.0	7100	9000	0.68
1208	1208K	40	80	18	19.0	6.95	8500	10000	0.42
2208	2208K		80	23	31.9	10	7500	9000	0.51
1308	1308K		90	23	33.8	11.2	6700	8000	0.72
2308	2308K		90	33	54.0	16.0	6300	7500	0.93
1209	1209K	45	85	19	22.9	7.87	7500	9000	0.47
2209	2209K		85	23	32.5	10.6	7000	8500	0.55
1309	1309K		100	25	39.0	13.4	6300	7500	0.96
2309	2309K		100	36	63.7	19.3	5600	6700	1.25
1210	1210K	50	90	20	26.5	9.15	7000	8500	0.53
2210	2210K		90	23	33.8	11.2	6300	7500	0.60
1310	1310K		110	27	43.6	14.0	5600	6700	1.2
2310	2310K		110	40	63.7	20.0	5300	6300	1.65
