規格	主要吋法					ab	Da	da		Da	Cr	Cor	容許回轉數	質量
NAF(W)	d	D	C	rs min	F		最大mm	最小mm	最大mm		N	N	rpm 注二)	g
NAF61710	6	17	10	0.3	10	12.4	15	8	9.7	10.4	4100	4500	28000	14
NAF72012	7	20	12	0.3	10	13.5	18	9	9.7	10.4	6000	6000	28000	23
NAF92212	9	22	12	0.3	12	17.5	20	11	11.5	12.4	9000	8400	26000	24
NAF102213	10	22	13	0.3	14	17.6	20	12	13	14.6	7800	9400	24000	26
NAFW102220	10	22	20	0.3	14	17.6	20	12	13	14.6	10800	14200	24000	40
NAF102612	10	26	12	0.3	14	19.4	24	12	13	14.6	9800	9700	24000	36
NAF122413	12	24	13	0.3	16	19.6	22	14	15	16.6	8600	11000	23000	30
NAFW122420	12	24	20	0.3	16	19.6	22	14	15	16.6	11900	16700	23000	45
NAF122812	12	28	12	0.3	16	21.4	26	14	15	16.6	10500	10900	23000	40
NAF152813	15	28	13	0.3	20	23.6	26	17	19	20.6	9600	13500	20000	37
NAFW152826	15	28	26	0.3	20	23.6	26	17	19	20.6	16500	27100	20000	76
NAF153212	15	32	12	0.3	20	25.4	30	17	19	20.6	12400	14300	20000	51
NAF173013	17	30	13	0.3	22	25.6	28	19	21	22.6	10200	15200	18000	43
NAFW173026	17	30	26	0.3	22	25.6	28	19	21	22.6	17600	30300	18000	85
NAF173516	17	35	16	0.3	22	27.8	33	19	21	22.6	17600	20900	18000	77
NAFW173532	17	35	32	0.3	22	27.8	33	19	21	22.6	30200	41900	18000	155
NAF203517	20	35	17	0.3	25	29.5	33	22	24	25.6	17300	26600	16000	75
NAFW203526	20	35	26	0.3	25	29.5	33	22	24	25.6	22500	37200	16000	114
NAF203716	20	37	16	0.3	25	30.4	35	22	24	25.6	19400	24500	16000	80
NAFW203732	20	37	32	0.3	25	30.4	35	22	24	25.6	33200	49000	16000	158
NAF254017	25	40	17	0.3	30	34.5	38	27	29	30.6	18600	31100	13000	88
NWAF254026	25	40	26	0.3	30	34.5	38	27	29	30.6	24200	43400	13000	136
NAF254216	25	42	16	0.3	30	35.4	40	27	29	30.6	20800	28300	13000	94
NAW254232	25	42	32	0.3	30	35.4	40	27	29	30.6	35700	56800	13000	187
NAF304517	30	45	17	0.3	35	39.5	43	32	34	35.6	20500	36900	11000	100
NAFW304526	30	45	26	0.3	35	39.5	43	32	34	35.6	26600	51600	11000	155
NAF304716	30	47	13	0.3	35	40.4	45	32	34	35.6	23000	33800	11000	108
NAFW304732	30	47	32	0.3	35	40.4	45	32	34	35.6	39500	67800	11000	215
NAF355017	35	50	17	0.3	40	43.5	48	37	39	40.8	22200	42700	10000	115
NAFW355034	35	50	34	0.3	40	43.5	48	37	39	40.8	38000	85300	10000	230
NAF355520	35	55	20	0.3	40	45.2	53	37	39	40.8	31500	48000	10000	188
NAFW355540	35	55	40	0.3	40	45.2	53	37	39	40.8	53900	96000	10000	375
NAF405517	40	55	17	0.3	45	48.5	53	42	44	45.8	23200	47200	10000	129
NAFW405534	40	55	34	0.3	45	48.5	53	42	44	45.8	39900	94200	10000	255
NAF406220	40	62	20	0.3	45	50.9	60	42	44	45.8	33200	53300	9000	236
NAFW406240	40	62	40	0.3	45	50.9	60	42	44	45.8	57000	106900	9000	475
NAF456220	45	62	20	0.3	50	54.2	60	47	49	50.8	27100	59300	8000	197
NAFW456240	45	62	40	0.3	50	54.2	60	49	49.5	50.8	46400	118700	8000	389
NAF457220	45	72	20	0.6	55	60.9	68	49	54	55.8	37400	66400	7500	340
NAFW457240	45	72	40	0.6	55	60.9	68	49	54	55.8	64100	132400	7500	685
NAF506820	50	68	20	0.6	55	59.5	64	54	54.5	55.8	28500	66000	7500	230
NAFW506840	50	68	40	0.6	55	59.5	64	54	54.5	55.8	48900	132400	7500	465
NAF507820	50	78	20	1	60	66.3	73	55	59	60.8	38900	71700	6500	390
NAWF507840	50	78	40	1	60	66.3	73	55	59	60.8	66700	143200	6500	775
NAF558530	55	85	30	1	65	72	80	60	63	66	59300	127500	6000	680
NAFW558560	55	85	60	1	65	72	80	60	63	66	102000	254000	6000	1380
NAF609030	60	90	30	1	70	77	85	65	68	71	61200	135300	5500	740
NAFW609060	60	90	60	1	70	77	85	65	68	71	104900	271600	5500	1470
NAF659530	65	95	30	1	75	82	90	70	73	76	63200	144200	5500	800
NAFW659560	65	95	60	1	75	82	90	70	73	76	108900	289300	5500	1570
NAF7010030	70	100	30	1	80	87	95	75	78	81	64900	153000	5000	840
NAFW7010060	70	100	60	1	80	87	95	75	78	81	111800	306000	5000	1670
NAF7510530	75	105	30	1	85	92	100	80	83	86	66600	160800	4800	890
NAFW8011030	80	110	30	1	90	97	105	85	88	91	69500	173600	4500	930
NAF8511530	85	115	30	1	95	102	110	90	93	96	70900	182400	4200	970
NAFW9012030	90	120	30	1	100	107	115	95	98	101	72600	191200	4000	1040
