130307叉车轴承、30507叉车轴承、130607叉车轴承-南京轴承厂

轴承型号 Bearing No.		类型 Type	尺寸 Dimensions(mm)								轴承型号 Bearing No.
I	II	类型 Type	d	D	C	B	R1	R2	偏移e	圆弧 R 斜度α	III

130304	L20304	B	20	60	16	15	2	2	1.0
30505	80505K1	A	25	70	27	15	2.5	2.5
130205	80505K2	B	25	70	17	15	2.5	2.5	2.0		L20205
30705		A	25	70	28	15	2.5	2.5			W120205
30805	80505K	A	25	80	22	16	3	3
30805K	180705K	A	30	80	22	17	3	3
30306		A	30	76	20	19	3	5
130306	80606K	B	30	78	23	19	3.5	3.5	4.0
110306F		M	30	77	23	19	3	5	4.0	R200	L10306
110306H		M	30	78	23	19	3	5	4.0	R200	L10306
110306L		M	30	79	23	19	3	5	4.0	R200	L10306
130706	180706K	B	30	91.5	24	19	2	5	5.0
130706K		B	30	91.5	24	20	2	5	4.0
30806		A	30	90	22	17	3	3
30307		A	35	80	25	21	3	3
130307		B	35	102	25.5	21	2	5	4.5
30507	80507K	A	35	100	26	18	2	2
130607	80607K	B	35	102	25.4	20	3.5	3.5	5.4
30807	80307K	A	35	90	31.34	21	3	3
30208	80508K	A	40	116	24.5	18	3	3 or 8			L20208
30208K	80508K1	A	40	110	29	18	3	3 or 8			Y20208
30208K1	80508Y1	K	40	112.3	29	18	3	3 or 8	2°30'		Y30208
30508K	80508Y	A	40	112.3	24.5	18	3	3 or 8
30308	S20308	A	40	115	32	23	6	6
30308S		A	40	111	30	23	3	10
110308S		M	40	103	27	23	3	5.5	4.0	R200	L40308
110308M		M	40	104	27	23	3	5.5	4.0	R200	L40308
110308L		M	40	105	27	23	3	5.5	4.0	R200	L40308
10308S		M	40	99	30	23	3	7		R200	780308
10308M		M	40	100	30	23	3	7		R200	780308
10308L		M	40	101	30	23	3	7		R200	780308
30308M		A	40	112	30	23	3	10
30308L		A	40	113	30	23	3	10
130308	80608K	B	40	104	27	23	3.5	3.5	4.0
130308K		K	40	109.7	28	23	7	5	3.5	3°29'
30708	180708K	A	40	109.7	32	23	3	7			80708K
30309		A	45	119	30	25	3	3
130309K		K	45	118.5	26	25	5	5	1.0	3°29'
130709	80709K	B	45	119	29	25	3.5	3.5	4.0
10709S		M	45	114	35	25	3	8		R200	960709S
10709M		M	45	115	35	25	3	8		R200	960769M
10709L		M	45	116	35	25	3	8		R200	960709L
10309S		M	45	117	40	25	5	8		R200
10309M		M	45	118	40	25	5	8		R200
10309L		M	45	119	40	25	5	8		R200
30710	80710K	A	50	115.3	34	25	3	3
30810K1	30810K	K	50	117.5	34	25	5	5	w	3°29'
