轴径

轴承型号

外形尺寸(mm)

基本额定负荷(N)

极限转速(rpm)

参考重量

(mm)

新型号

原型号

内径

外径

宽度

动负荷

静负荷

脂润滑

油润滑

(kg)

d

D

B

Mass

4

HK0408TN

37941/4

4

8

8

1540

1070

24000

40000

1.6

5

HK0509TN

47941/5

5

9

9

220

1790

22000

36000

2

6

HK0608

37941/6

6

10

8

1830

1550

20000

32000

2.1

HK0609

47941/6

6

10

9

2650

2400

18000

30000

2.2

7

HK0709

47941/7

7

11

9

2800

2150

16000

27000

2.3

8

HK0808

37941/8

8

12

8

2550

2400

13000

21000

2.7

HK0814

57941/8

8

12

10

3700

3450

13000

21000

3

9

HK0908

37941/9

9

13

8

3650

4050

15000

25000

3

HK0910

57941/9

9

13

10

4050

4250

15000

25000

4

HK0912

67941/9

9

13

12

5000

6000

15000

25000

4.6

10

HK1010

57941/10

10

14

10

3900

4800

11500

19000

4.1

HK1012

67941/10

10

14

12

5000

6300

11500

19000

4.8

HK1015

10

14

15

6700

7800

11500

19000

6

12

HK1210

57941/12

12

16

10

4150

5800

11500

19000

4.6

HK1212

37942/12

12

18

12

3800

5100

9000

15000

5.6

13

HK1312

7949/13

13

19

12

6200

7100

11000

17000

8.9

14

HK1412

37941/14

14

20

12

6800

7500

9600

16000

10.5

15

HK1512

37941/15

15

21

12

7000

8400

8400

14000

11.1

HK1516

7941/15

15

21

16

9800

11400

8400

14000

15

HK1520

77941/15

15

21

20

11000

16800

HK1522

15

21

22

10400

16500

8400

14000

20.4

16

HK1612

37941/16

16

22

12

7100

9200

8400

14000

11.7

HK1616

57941/16

16

22

16

10100

14300

8400

14000

15.8

HK1622

16

22

22

11100

17400

8400

14000

21.7

17

HK1712

37941/17

17

23

12

6900

9300

7800

13000

12.2

HK1714

49741/17

17

23

14

6800

10200

6000

10000

14

HK1718

7942/17

17

23

18

9500

10600

6000

10000

19

HK1720

17

23

20

21

HK1722

7943/17

17

23

22

24

18

HK1812

39741/18

18

24

12

7100

9900

7200

12000

13.1

HK1816

57941/18

18

24

16

106500

15300

7200

12000

17.5

HK1820

18

24

20

19

HK1916

19

25

16

HK1920

19

25

20

20

HK2010

27941/20

20

26

10

5900

7200

6000

10000

11.8

HK2012

37941/20

20

26

12

7600

10100

6000

10000

14.1

HK2014

47941/20

20

26

14

9700

18100

5400

9000

15.7

HK2016

57941/20

20

26

16

11700

29100

6000

10000

19.3

HK2018

67941/20

20

26

18

7900

12800

5400

9000

23.3

HK2020

7942/20

20

26

20

13700

24000

6000

10000

24.1

HK2025

7943/20

20

26

25

9100

14800

6000

9900

28

HK2030

20

26

30

21800

40000

6100

10100

34.7

22

HK2210

27941/22

22

28

10

7200

9500

6000

10010

12.3

HK2212

37941/22

22

28

12

8100

10400

6000

10010

15

HK2216

57941/22

22

28

16

11400

18100

6000

10010

20.9

HK2220

77941/22

22

28

20

14500

25000

6000

10010

26.2

25

HK2512

27941/25

25

32

12

10000

14200

5400

9000

22

HK2514

37941/25

25

32

14

13600

18700

5400

9000

21.9

HK2516

7941/25

25

32

16

13600

20000

5400

9000

27.3

HK2518

5791/25

25

32

18

17500

25800

5400

9000

28.2

HK2520

67941/25

25

32

20

17900

30000

5400

9000

34.1

HK2525

7943/25

25

32

25

22200

36700

5400

9000

40

HK2526

25

32

26

22500

42000

5400

9000

44.8

HK2538

87941/25

25

32

38

30000

58000

5400

9000

64.7

28

HK2816

47941/28

28

35

16

15400

22500

5220

8700

30.1

HK2818

57941/28

28

35

18

18500

29300

5220

8700

31.7

HK2820

679741/28

28

35

20

18900

32000

5220

8700

37.6

30

HK3012

27941/30

30

37

12

10100

16200

4850

8100

24

HK3016

47941/30

30

37

16

15200

27000

4850

8100

32

HK3018

57941/30

30

37

18

19200

31500

4850

8100

33.6

HK3020

67941/30

30

37

20

19700

33500

4850

8100

40.1

HK3026

30

37

26

24000

50000

4850

8100

52.9

HK3038

30

37

38

32500

74000

4850

8100

76.1

32

HK3224

77941/32

32

38

24

25500

52000

4300

7300

50.7

HK3232

97941/32

32

39

32

22600

54300

4300

7100

66.4

35

HK3512

27941/35

35

42

12

12100

19300

4300

7100

27.7

HK3516

47941/35

35

42

16

15700

27500

4300

7100

36.9

HK3520

67941/35

35

42

20

20800

41000

4300

7100

46.1

40

HK4012

29741/40

40

47

12

14000

24300

3800

6300

31.1

HK4016

49741/40

40

47

16

20000

38500

3800

300

41.4

HK4020

67941/40

40

47

20

25500

52000

3800

6300

51.8

45

HK4512

29741/4

45

52

12

12900

22500

3500

5800

34.8

HK4516

49741/45

45

52

16

19300

38000

3500

5800

50

HK4520

67941/45

45

52

20

22000

51000

3500

5800

56

50

HK5020

57941/50

50

58

20

28000

60000

3500

5300

72

HK5025

7943/50

50

58

25

29500

80000

3500

5300

90

55

HK5520

57941/55

55

63

20

33200

60000

2700

4500

107

HK5528

87941/55

55

63

28

39100

98000

2700

4500

111

60

HK6012

60

68

12

12400

29000

2400

4000

49.2

HK6020

57941/60

60

68

20

30500

72000

2400

4000

86

HK6032

87941/60

60

68

32

50000

131000

2400

4000

134
